香猪ENTPD1基因3'UTR的SINE插入下调其基因表达

doi:10.11843/j.issn.0366-6964.2025.09.015

Abstract

Abstract:

The study aimed to investigate the population polymorphism of short interspersed nuclear element (SINE) insertions/deletions in the 3'UTR of the ENTPD1 gene and their effect on gene expression in the Xiang pig. Xiang pigs were used as research subjects and Large White pigs were used as controls. The detection of population polymorphism of SINE insertions/deletions in the 3'UTR region of the ENTPD1 gene in Xiang pig and Large White pig populations was performed by PCR. The functional elements in SINE sequences was analyzed using databases and softwares such as UCSC, SINE Base, miRNA Base, PITA and RBP suite; The mRNA levels of ENTPD1 in different tissues (heart, liver, spleen, lung and kidney) of individuals of 6-month-old and mRNA levels of ENTPD1 in lung tissues of individuals with different genotypes of healthy adult Xiang pig was detected using Real-time fluorescence quantitative PCR (RT-qPCR) technology. The protein levels of ENTPD1 in lung tissues of individuals with different genotypes was detected using Western blotting technique. The results showed that there was a 297 bp SINE polymorphism site in the 3'UTR of ENTPD1 in Xiang pig, it was located at 466 bp downstream of the terminator codon. Bioinformatic analysis revealed that the SINE belonged to the Pre0_SS tRNA family and contained the RNA polymerase Ⅲ promoter, multiple RNA-binding proteins, and binding sites for miRNAs; Three genotypes, insertion (SINE+/+), deletion (SINE-/-) and heterozygote (SINE+/-), were detected in Xiang pigs and Large White pigs. The frequency of deletion (SINE-/-) genotype in Xiang pigs was significantly higher than that in Large White pigs (P < 0.01), and the frequency of SINE- allele was significantly higher than that in Large White pigs (P < 0.05). The variation showed moderate polymorphism in both populations, but only in Xiang pig population conformed to Hardy-Weinberg equilibrium. Detection of ENTPD1 mRNA in different tissues of Xiang pig showed higher mRNA levels in spleen and lung tissues. The mRNA and protein assays of ENTPD1 in lung tissues of individuals with different genotypes of Xiang pigs showed that the mRNA levels of SINE-/- and SINE+/- genotypes were highly significantly higher than those of SINE+/+, and the protein levels of SINE-/- genotypes were highly significantly higher than those of SINE+/- and SINE+/+. The results suggest that SINE insertion negatively regulates the expression of ENTPD1 gene.

Key words: ENTPD1, 3'UTR, SINE, gene expression, Xiang pig

CLC Number:

S828.2

TIAN Jiao, LONG Juyan, CHEN Xia, CEN Xiaoli, NIU Xi, HUANG Shihui, WANG Jiafu, RAN Xueqin. Down-regulation of Gene Expression by SINE Insertion in the 3'UTR of the ENTPD1 Gene in the Xiang Pig[J]. Acta Veterinaria et Zootechnica Sinica, 2025, 56(9): 4303-4314.

Figures/Tables 9

Table 1

Fig. 1

Fig. 2

Table 2

Table 3

Table 4

Fig. 3

Fig. 4

Fig. 5

References 41

1	LI X Y , MOESTA A K , XIAO C , et al. Targeting CD39 in cancer reveals an extracellular ATP- and inflammasome-driven tumor immunity[J]. Cancer Discov, 2019, 9 (12): 1754- 1773. doi: 10.1158/2159-8290.CD-19-0541
2	SCHADLICH I S , WINZER R , STABERNACK J , et al. The role of the ATP-adenosine axis in ischemic stroke[J]. Semin Immunopathol, 2023, 45 (3): 347- 365. doi: 10.1007/s00281-023-00987-3
3	WANG C , YI NQ , SN Z , et al. Progress on role of extracellular ATP and its metabolite adenosine in immunoregulation: Review[J]. Xi Bao Yu Fen Zi Mian Yi Xue Za Zhi, 2020, 36 (12): 1134- 1140.
4	GRASSI F , MARINO R . The P2X7 receptor in mucosal adaptive immunity[J]. Purinergic Signal, 2024, 20 (1): 9- 19. doi: 10.1007/s11302-023-09939-w
5	VUERICH M , ROBSON S C , LONGHI M S . Ectonucleotidases in intestinal and hepatic inflammation[J]. Front Immunol, 2019, 10, 507. doi: 10.3389/fimmu.2019.00507
6	GUTKNECHT DA SILVA J L , PASSOS D F , CABRAL F L , et al. Istradefylline induces A2A/P2X7 crosstalk expression inducing pro-inflammatory signal, and reduces AKT/mTOR signaling in melanoma-bearing mice[J]. Med Oncol, 2023, 40 (6): 178. doi: 10.1007/s12032-023-02033-6
7	PENG Z W , ROTHWEILER S , WEI G , et al. The ectonucleotidase ENTPD1/CD39 limits biliary injury and fibrosis in mouse models of sclerosing cholangitis[J]. Hepatol Commun, 2017, 1 (9): 957- 972. doi: 10.1002/hep4.1084
8	LEE N T , SAVVIDOU I , SELAN C , et al. Development of endothelial-targeted CD39 as a therapy for ischemic stroke[J]. J Thromb Haemost, 2024, 22 (8): 2331- 2344. doi: 10.1016/j.jtha.2024.04.023
9	ZENG J , NING Z , WANG Y , et al. Implications of CD39 in immune-related diseases[J]. Int Immunopharmacol, 2020, 89, 107055. doi: 10.1016/j.intimp.2020.107055
10	SAVIO L E B , DE ANDRADE MELLO P , FIGLIUOLO V R , et al. CD39 limits P2X7 receptor inflammatory signaling a nd attenuates sepsis-induced liver injury[J]. J Hepatol, 2017, 67 (4): 716- 726. doi: 10.1016/j.jhep.2017.05.021
11	MALONEY J P , BRANCHFORD B R , BRODSKY G L , et al. The ENTPD1 promoter polymorphism -860 A>G (rs3814159) is associated with increased gene transcription, protein expression, CD39/NTPDase1 enzymatic activity, and thromboembolism risk[J]. Faseb j, 2017, 31 (7): 2771- 2784. doi: 10.1096/fj.201600344R
12	ZHAO P , GU L , GAO Y , et al. Young SINEs in pig genomes impact gene regulation, genetic diversity, and complex traits[J]. Commun Biol, 2023, 6 (1): 894. doi: 10.1038/s42003-023-05234-x
13	TAM P L F , LEUNG D . The molecular impacts of retrotransposons in development and diseases[J]. Int J Mol Sci, 2023, 24 (22): 16418. doi: 10.3390/ijms242216418
14	ZHENG Y , CHEN C , WANG M , et al. SINE insertion in the pig carbonic anhydrase 5B (CA5B) gene is associated with changes in gene expression and phenotypic variation[J]. Animals (Basel), 2023, 13 (12): 1942.
15	KRAMEROV D A , VASSETZKY N S . Origin and evolution of SINEs in eukaryotic genomes[J]. Heredity (Edinb), 2011, 107 (6): 487- 495. doi: 10.1038/hdy.2011.43
16	SENFT A D , MACFARLAN T S . Transposable elements shape the evolution of mammalian development[J]. Nat Rev Genet, 2021, 22 (11): 691- 711. doi: 10.1038/s41576-021-00385-1
17	CHOI J D , DEL PINTO L A , SUTTER N B . SINE retrotransposons import polyadenylation signals to 3'UTRs in dog (Canis familiaris)[J]. Mob DNA, 2025, 16 (1): 1. doi: 10.1186/s13100-024-00338-5
18	WANG X , CHI C , HE J , et al. SINE insertion may act as a repressor to affect the expression of pig LEPROT and growth traits[J]. Genes (Basel), 2022, 13 (8): 1422. doi: 10.3390/genes13081422
19	QI F , CHEN X , WANG J , et al. Genome-wide characterization of structure variations in the Xiang pig for genetic resistance to African swine fever[J]. Virulence, 2024, 15 (1): 2382762. doi: 10.1080/21505594.2024.2382762
20	梁小芬, 冉雪琴, 牛熙, 等. 香猪CYP3A29基因3'-UTR结构变异及其与肌肉雄激素水平的关联分析[J]. 中国畜牧兽医, 2023, 50 (8): 3199- 3209.
	LIANG X F , RAN X Q , NIU X , et al. Analysis of 3'-UTR Structural variations of CYP3A29 gene in Xiang pigs and its association with muscle androgen levels[J]. China Animal Husbandry & Veterinary Medicine, 2023, 50 (8): 3199- 3209.
21	PENG Z W , ROTHWEILER S , WEI G , et al. The ectonucleotidase ENTPD1/CD39 limits biliary injury and fibrosis in mouse models of sclerosing cholangitis[J]. Hepatol Commun, 2017, 1 (9): 957- 972. doi: 10.1002/hep4.1084
22	SABATEL C , BUREAU F . The innate immune brakes of the lung[J]. Front Immunol, 2023, 14, 1111298. doi: 10.3389/fimmu.2023.1111298
23	RYANTO G R T , SURAYA R , NAGANO T . The importance of lung innate immunity during health and disease[J]. Pathogens, 2025, 14 (1): 91. doi: 10.3390/pathogens14010091
24	WANG L , LI Y J , YANG X , et al. Purinergic signaling: a potential therapeutic target for ischemic stroke[J]. Purinergic Signal, 2023, 19 (1): 173- 183. doi: 10.1007/s11302-022-09905-y
25	ROBSON S C , WU Y , SUN X , et al. Ectonucleotidases of CD39 family modulate vascular inflammation and thrombosis in transplantation[J]. Semin Thromb Hemost, 2005, 31 (2): 217- 233. doi: 10.1055/s-2005-869527
26	ORTIZ M A , DIAZ-TORNÉ C , DE AGUSTIN J J , et al. Altered CD39 and CD73 expression in rheumatoid arthritis: Implications for disease activity and treatment response[J]. Biomolecules, 2023, 14 (1): 1. doi: 10.3390/biom14010001
27	李默晗. CD39通过下调PAI-1表达与活性保护缺血性卒中脑组织[D]. 长沙: 中南大学, 2022.
	LI M H. CD39 protects the brain tissue of ischemic stroke by down-regulating the expression and activity of PAI-1[D]. Changsha: Zhongnan University, 2022. (in Chinese)
28	夏国庆. ATP通过P2X4和CD39调控酒精相关性脂肪性肝炎机制研究[D]. 合肥: 安徽医科大学, 2022.
	XIA G Q. Research on the Mechanism of ATP regulating Alcoholic Steatohepatitis through P2X4 and CD39[D]. Hefie: Anhui Medical University, 2022. (in Chinese)
29	杜鹏. CD39-腺苷-A2B信号通路在低温携氧机械灌注改善DCD肝脏缺血再灌注损伤中的作用及机制研究[D]. 南昌: 南昌大学, 2022.
	DU P. Role and mechanism of CD39-adenosine-A2B signaling pathway in hypothermic oxygen-carrying mechanical perfusion to ameliorate liver ischemia-reperfusion injury in DCD[D]. Nanchang: Nanchang University, 2022. (in Chinese)
30	LIU J J , RAN X Q , LI S , et al. Polymorphism in the first intron of follicle stimulating hormone beta gene in three Chinese pig breeds and two European pig breeds[J]. Anim Reprod Sci, 2009, 111 (2-4): 369- 375. doi: 10.1016/j.anireprosci.2008.03.004
31	MAGOTRA A , NASKAR S , DAS B , et al. A comparative study of SINE insertion together with a mutation in the first intron of follicle stimulating hormone beta gene in indigenous pigs of India[J]. Mol Biol Rep, 2015, 42 (2): 465- 470. doi: 10.1007/s11033-014-3789-y
32	黄月丽, 冉雪琴, 牛熙, 等. 香猪CHD3基因3'-侧翼区264 bp结构变异的研究[J]. 中国畜牧兽医, 2022, 49 (8): 3026- 3035.
	HUANG Y L , RAN X Q , NIU X , et al. A study of 264 bp structural variation in the 3'-flanking region of the CHD3 gene of the balsam pig[J]. China Animal Husbandry & Veterinary Medicine, 2022, 49 (8): 3026- 3035.
33	ZHAO P , GU L , GAO Y , et al. Young SINEs in pig genomes impact gene regulation, genetic diversity, and complex traits[J]. Commun Biol, 2023, 6 (1): 894. doi: 10.1038/s42003-023-05234-x
34	TUCKER J M , GLAUNSINGER B A . Host noncoding retrotransposons induced by DNA viruses: a SINE of infection?[J]. J Virol, 2017, 91 (23): e00982- 17.
35	KARIJOLICH J , ABERNATHY E , GLAUNSINGER B A . Infection-induced retrotransposon-derived noncoding RNAs enhance herpesviral gene expression via the NF-κB pathway[J]. PLoS Pathog, 2015, 11 (11): e1005260. doi: 10.1371/journal.ppat.1005260
36	HWANG H , CHANG H R , BAEK D . Determinants of functional microRNA targeting[J]. Mol Cells, 2023, 46 (1): 21- 32. doi: 10.14348/molcells.2023.2157
37	XI E , BAI J , ZHANG K , et al. Genomic variants disrupt miRNA-mRNA regulation[J]. Chem Biodivers, 2022, 19 (10): e202200623. doi: 10.1002/cbdv.202200623
38	李河林, 蒋玉芬, 程娜, 等. 筛选的差异表达microRNAs对猪卵母细胞Npm2基因的表达调控及作用研究[J]. 畜牧兽医学报, 2024, 55 (11): 5035- 5049. doi: 10.11843/j.issn.0366-6964.2024.11.021
	LI H L , JIANG Y F , CHENG N , et al. Regulation of Npm2 gene expression and role of screened differentially expressed microRNAs in porcine oocytes[J]. Acta Veterinaria et Zootechnica Sinica, 2024, 55 (11): 5035- 5049. doi: 10.11843/j.issn.0366-6964.2024.11.021
39	KOH D , BIN JEON H , OH C , et al. RNA-binding proteins in cellular senescence[J]. Mech Ageing Dev, 2023, 214, 111853. doi: 10.1016/j.mad.2023.111853
40	余祖华, 高梦茹, 齐志颖, 等. RNA结合蛋白ELAVL1的功能及其调控病毒复制的研究进展[J]. 畜牧兽医学报, 2024, 55 (5): 1914- 1925. doi: 10.11843/j.issn.0366-6964.2024.05.010
	YU Z H , GAO M R , QI Z Y , et al. Advances in the function of the RNA-binding protein ELAVL1 and its regulation of viral replication[J]. Acta Veterinaria et Zootechnica Sinica, 2024, 55 (5): 1914- 1925. doi: 10.11843/j.issn.0366-6964.2024.05.010
41	AMEIS D , LIU F , KIRBY E , et al. The RNA-binding protein Quaking regulates multiciliated and basal cell abundance in the developing lung[J]. Am J Physiol Lung Cell Mol Physiol, 2021, 320 (4): L557- L567. doi: 10.1152/ajplung.00481.2019

引物名称 Primer name	引物序列(5′→3′) Primer sequence	产物长度/bp Length	退火温度/℃ Annealing temperature	用途 Application
ENTPD1-3′UTR-F	GAACTGAGAATCCTGAGTCCTGT	571/274	58	SV分型
ENTPD1-3′UTR-R	CATAAGTTCCTTCACAAGCCTCT
qENTPD1-F	CTCCCACTCCACCTATGTCTTC	160	60	mRNA水平分析
qENTPD1-R	AGTTTTCTTCTCACTCCAGCCA
qGAPDH-F	AGGTCGGAGTGAACGGATTTG	118	60
qGAPDH-R	ACCATGTAGTGGAGGTCAATGAAG

序号 Number	RNA结合蛋白 RNA-binding protein	结合位置 Binding position	结合序列 Binding sequence	数量 Number	分数 Score
1	富脯氨酸和谷氨酰胺的剪接因子(SFPQ)	112~118	GUGGUGU	1	0.58
2	Lin-28同系物A(LIN28A)	113~119;159~165	UGGUGUA	2	0.98
3	多聚结合蛋白1(PCBP1)	194~200 67~73	CCUAGCC CCUGCCC	1 1	0.72 0.56
5	脆性X信使核糖核蛋白1(FMR1)	35~41	CGACUAG	1	0.83
6	富丝氨酸和精氨酸的剪接因子7(SRSF7)	33~40	UCCGACUA	1	0.99
7	富丝氨酸和精氨酸的剪接因子9(SRSF9)	14~20	UGGCGCA	1	0.99
8	FUS RNA结合蛋白(FUS)	114~117;160~163	GGUG	2	0.67
9	FMR1常染色体同系物2(FXR2)	126~132	AGACGCG	1	0.97
10	胰岛素样生长因子2 mRNA结合蛋白1(IGF2BP1)	138~148	GAUCCUGCGUU	1	0.60
11	多聚嘧啶区结合蛋1(PTBP1)	72~78	CCUUGCU	1	0.51
12	Pumilio RNA结合家族成员1(PUM1)	116~119;162~165	UGUA	2	0.67

序号 Number	miRNA名称 miRNA	结合位置 Binding position	序列(5′→3′) Sequence	自由能/(kJ·mol^-1) Free energy
1	ssc-miR-744	209~217	AGCTCCGAT	-10.67
2	ssc-miR-4331-3p	209~215	AGCTCCG	-11.61
3	ssc-miR-214-5p	195~203	AGGCTGGCA	-10.52
4	ssc-miR-9802-3p	100~107	GCCCTTGC	-11.57
5	ssc-miR-326	258~266	GCCCAAAGA	-11.06
6	ssc-miR-330	258~266	GCCCAAAGA	-12.02
7	ssc-miR-885-3p	128~135	CGTTGCCG	-10.32
8	ssc-miR-99b	84~91	TGCGGGTT	-10.75
9	ssc-miR-652	78~86	TGGGGTTGC	-10.23
10	ssc-miR-9805-3p	168~176	GATCCTGCG	-10.87
11	ssc-miR-7137-5p	34~42	GTTCCCGTC	-10.62
12	ssc-miR-193a-5p	254~262	AAAGACCAA	-14.65
13	ssc-miR-140-5p	255~263	AAGACCAAA	-11.56

群体 Population	样本数/头 Sample	基因型频率(%) Genotype frequency			等位基因频率/% Allele frequency		HWE test P	群体遗传特征 Population genetic characteristics
群体 Population	样本数/头 Sample	SINE+/+	SINE+/-	SINE-/-	SINE+	SINE-	HWE test P	纯合度 Ho	杂合度 He	有效等位基因数Ne	多态信息含量PIC
香猪 Xiang pig	302	70 (23.18)	124 (41.06)	108 (35.76)^A	43.71	56.29^A	0.13	0.51	0.49	1.97	0.37
大白猪 Large White pig	170	54 (31.76)	102 (60.00)	14 (8.24)^C	61.76	38.24^B	0.03	0.53	0.47	1.90	0.36
