产超广谱β内酰胺酶和碳青霉烯酶肺炎克雷伯菌替加环素耐药性机制的初步分析

doi:10.11843/j.issn.0366-6964.2025.07.042

摘要/Abstract

摘要：

耐碳青霉烯类肺炎克雷伯菌(carbapenem resistant Klebsiella pneumoniae，CRKP)的报道逐年增多，替加环素已成为治疗耐碳青霉烯类肺炎克雷伯菌感染的最后一道防线，本研究旨在对3株耐碳青霉烯类肺炎克雷伯菌的替加环素耐药性机制进行初步研究。采用微量肉汤稀释法测定对替加环素的敏感性并评估外排泵抑制剂(PAβN)对耐药性的影响；结合前期全基因组测序结果，采用PCR验证与替加环素耐药相关基因及其调控因子、孔蛋白相关基因的转录[acrAB-tolC、oqxAB、msbA、kexD、kdeA、kpnEF、kpnGH、Ompk37、OmpA、ramA、ramR、marA、rarA、acrR、tet(X4)、tetA]，通过实时荧光定量PCR检测耐药菌株和敏感菌株之间的基因转录水平差异。结果显示：体外药敏试验发现3株肺炎克雷伯菌KP30535、KP30845和KP30727分别对替加环素耐药、中介、敏感。外源添加PAβN增加了菌株对替加环素的敏感性。实时荧光定量PCR结果表明，耐药菌株(KP30535)和中介菌株(KP30845)中acrAB、kpnGH、ramA转录水平显著(P < 0.05)高于对照菌ATCC13883，KP30535中kpnE转录水平显著(P < 0.01)高于对照菌；KP30727中acrB、ramA、ramR转录水平显著(P < 0.05)高于对照菌；3株菌中孔蛋白Ompk37、OmpA转录水平极显著(P < 0.001)低于对照菌。Spearman相关性分析表明，acrAB、kpnGH和kexD和孔蛋白OmpA与菌株替加环素耐药表型相关($|r|$ ≥0.6)。综上，acrAB、kpnGH、kexD和孔蛋白OmpA的差异表达是影响本研究中耐碳青霉烯类肺炎克雷伯菌对替加环素耐药性的重要因素，为后续更深入地研究提供参考依据。

关键词: 肺炎克雷伯菌, 替加环素, 耐药机制, 外排泵, 孔蛋白, 调控因子

Abstract:

The reports of carbapenem-resistant Klebsiella pneumoniae (CRKP) are increasing annually, and tigecycline has become the last line of defense for treating carbapenem-resistant Klebsiella pneumoniae (CRKP) infections, this article presents a preliminary study on the mechanism of tigecycline resistance in three strains of carbapenem-resistant Klebsiella pneumoniae. Broth microdilution method was used to determine the sensitivity of CRKP to tigecycline and evaluate the effect of efflux pump inhibitor, PAβN, on drug resistance. Combined with the results of the previous whole genome sequencing, polymerase chain reaction (PCR) testing was employed to validate the presence of genes and corresponding regulatory factors, porins (acrAB-tolC, oqxAB, msbA, kexD, kdeA, kpnEF, kpnGH, Ompk37, OmpA, ramA, ramR, marA, rarA, acrR, tet(X4), tetA) associated with tigecycline resistance, and differences in gene expression levels between resistant and sensitive strains were detected by real-time fluorescence quantitative PCR. In vitro drug susceptibility experiments showed that the three CRKP strains KP30535, KP30845 and KP30727 were resistant, intermediate and sensitive to tigecycline respectively. In vivo addition of PAβN increased the resistance of strain to tigecycline. The results of real-time quantitative fluorescence PCR showed that the transcription levels of acrAB, kpnGH and ramA in resistant strain KP30535 and intermediate strain KP30845 were significantly higher (P < 0.05) than those of the control strain ATCC13883, and the transcription level of kpnE in KP30535 was extremely higher (P < 0.01). The transcription levels of acrB, ramA and ramR in KP30727 were significantly higher (P < 0.05) than control. The transcription of porins Ompk37 and OmpA in the three strains were markedly lower (P < 0.001) than control. The results of Spearman correlation analysis showed that acrAB, kpnGH, kexD and the porin OmpA were associated with the antimicrobial resistance phenotype of the strain to tigecycline ($|r|$ ≥0.6). The preliminary research results indicate that the different expression of acrAB, kpnGH, kexD, and porin OmpA may be important factors affecting the resistance of CRKP to tigecycline in this study, which can provide reference for further in-depth research.

Key words: Klebsiella pneumoniae, tigecycline, resistance mechanism, efflux pump, porins, expression regulators

中图分类号:

R978

韦钰诗, 孙文, 庞晓敏, 王玉莲. 产超广谱β内酰胺酶和碳青霉烯酶肺炎克雷伯菌替加环素耐药性机制的初步分析[J]. 畜牧兽医学报, 2025, 56(7): 3507-3518.

WEI Yushi, SUN Wen, PANG Xiaomin, WANG Yulian. A Preliminary Study on the Mechanism of Tigecycline Resistance in ESBLs- and Carbapenemase-Producing Klebsiella pneumoniae[J]. Acta Veterinaria et Zootechnica Sinica, 2025, 56(7): 3507-3518.

图/表 9

表 1

图 1

表 2

表 3

表 4

图 2

图 3

图 4

表 5

参考文献 43

1	WARETH G , NEUBAUER H . The Animal-foods-environment interface of Klebsiella pneumoniae in Germany: an observational study on pathogenicity, resistance development and the current situation[J]. Vet Res, 2021, 52 (1): 16.
2	WANG G , ZHAO G , CHAO X , et al. The Characteristic of virulence, biofilm and antibiotic resistance of Klebsiella pneumoniae[J]. Int J Environ Res Public Health, 2020, 17 (17): 6278.
3	HU Y Y , CAI J C , ZHOU H W , et al. Rapid detection of porins by matrix-assisted laser desorption/ionization-time of flight mass spectrometry[J]. Front Microbiol, 2015, 6, 784.
4	EJAZ H , QAMAR M U , FARHANA A , et al. The rising tide of antibiotic resistance: A study on extended-spectrum beta-lactamase and carbapenem-resistant Escherichia coli and Klebsiella pneumoniae[J]. J Clin Lab Anal, 2024, 38 (10): e25081.
5	STOCKHOLM: ECDC. European centre for disease prevention and control. Antimicrobial resistance in the EU/EEA (EARS-Net)-Annual Epidemiological Report 2022[R]. 2023. https://www.ecdc.europa.eu. (2025-04-05).
6	胡付品, 郭燕, 朱德妹, 等. 2021年CHINET中国细菌耐药监测[J]. 中国感染与化疗杂志, 2022, 22 (5): 521- 530.
	HU F P , GUO Y , ZHU D M , et al. CHINET China bacterial resistance monitoring[J]. Chinese Journal Infection and Chemotherapy, 2022, 22 (25): 521- 530.
7	王浩, 张琰, 肖汉, 等. ICU肺炎克雷伯菌感染患者耐碳青霉烯类抗菌药物的危险因素及预后研究[J]. 河北医药, 2023, 45 (10): 1492- 1495.
	WANG H , ZHANG Y , XIAO H , et al. Klebsiella Pneumoniae bacteria infections in ICU penicillium carbon alkene antimicrobial drug resistance in patients with risk factors and prognosis of research[J]. Hebei Medical Journal, 2023, 45 (10): 1492- 1495.
8	王元春, 张丽华, 吴庆荣, 等. 临床常用抗菌药物组合对耐碳青霉烯类肺炎克雷伯菌的体外抗菌作用[J]. 临床合理用药, 2023, 16 (30): 33- 37.
	WANG Y C , ZHANG L H , WU Q R , et al. In vitro antimicrobial effect of a combination of commonly used antimicrobial drugs on carbapenem-resistant Klebsiella pneumoniae[J]. Clinical Rational Drug Use, 2023, 16 (30): 33- 37.
9	DU X , HE F , SHI Q , et al. The rapid emergence of tigecycline resistance in bla_KPC-2 harboring Klebsiella pneumoniae, as mediated in vivo by mutation in tetA during tigecycline treatment[J]. Front Microbiol, 2018, 9, 648.
10	肖婷婷, 肖永红. 替加环素临床应用剖析[J]. 医药导报, 2019, 38 (5): 544- 550.
	XIAO T T , XIAO Y H . Analysis of clinical application of tigecycline[J]. Herald of Medicine, 2019, 38 (5): 544- 550.
11	钟丽球, 刘锋. 肺炎克雷伯菌对碳青霉烯类的耐药机制及治疗策略[J]. 西北药学杂志, 2020, 35 (6): 967- 971.
	ZHONG L Q , LIU F . The resistance mechanism and treatment strategy of Klebsiella pneumoniae to carbapenems[J]. Northwest Journal of Pharmacy, 2020, 35 (6): 967- 971.
12	荆炜, 程于梦, 单新新, 等. 质粒介导的tet(A)突变体对肺炎克雷伯氏菌替加环素耐药的影响[J]. 浙江农业学报, 2018, 30 (5): 717- 721.
	JING W , CHENG Y M , DAN X X , et al. The effect of plasmid mediated tet(A) mutant on tigecycline resistance in Klebsiella pneumoniae[J]. Acta Agriculturae Zhejiangensis, 2018, 30 (5): 717- 721.
13	FDA. FDA Drug Safety Communication: FDA warns of increased risk of death with Ⅳ antibacterial Tygacil (tigecycline) and approves new Boxed Warning. 2013[Z]. FDA Drug Safety Communication issued 09-27-2013.
14	YAHAV D , LADOR A , PAUL M , et al. Efficacy and safety of tigecycline: a systematic review and meta-analysis[J]. J Antimicrob Chemother, 2011, 66 (9): 1963- 1971.
15	李耘, 郑波, 吕媛, 等. 中国细菌耐药监测研究2019-2020革兰氏阳性菌监测报告[J]. 中国临床药理学杂志, 2022, 38 (4): 369- 384.
	LI Y , ZHENG B , LV Y , et al. Research on bacterial resistance monitoring in China 2019-2020 Gram positive bacterial monitoring report[J]. Chinese Journal of Clinical Pharmacology, 2022, 38 (4): 369- 384.
16	庞晓敏. 不同宿主来源的肺炎克雷伯菌耐药性及毒力评估[D]. 武汉: 华中农业大学, 2023.
	PANG X M. Drug resistance and virulence assessment of Klebsiella pneumoniae from different host sources[D]. Wuhan: Huazhong Agricultural University, 2023. (in Chinese)
17	Clinical and Laboratory Standards Institute . Performance standards for antimicrobial susceptibility testing: Thirty-second informational supplement M100-S32[M]. Wayne, PA: CLSI, 2024.
18	苏文亚. 肺炎克雷伯氏菌替加环素耐药机制研究[D]. 济南: 山东大学, 2021.
	SU W Y. Study on the resistance mechanism of Klebsiella pneumoniae to tigecycline[D]. Jinan: Shandong University, 2021. (in Chinese)
19	SNOWDIN J W , MERCURO N J , MADAIO M P , et al. Case report: Successful treatment of OXA-23 Acinetobacter baumannii neurosurgical infection and meningitis with sulbactam-durlobactam combination therapy[J]. Front Med (Lausanne), 2024, 11, 1381123.
20	KÄLLMAN O , MOTAKEFI A , WRETLIND B , et al. Cefuroxime non-susceptibility in multidrug-resistant Klebsiella pneumoniae overexpressing ramA and acrA and expressing ompK35 at reduced levels[J]. J Antimicrob Chemother, 2008, 62 (5): 986- 990.
21	DOUMITH M , ELLINGTON M J , LIVERMORE D M , et al. Molecular mechanisms disrupting porin expression in ertapenem-resistant Klebsiella and Enterobacter spp. clinical isolates from the UK[J]. J Antimicrob Chemother, 2009, 63 (4): 659- 667.
22	ROY S , DATTA S , VISWANATHAN R , et al. Tigecycline susceptibility in Klebsiella pneumoniae and Escherichia coli causing neonatal septicaemia (2007-10) and role of an efflux pump in tigecycline non-susceptibility[J]. J Antimicrob Chemother, 2013, 68 (5): 1036- 1042.
23	廖凤慧. 碳青霉烯类抗菌药物耐药的肺炎克雷伯菌对替加环素的耐药性及耐药基因的研究[D]. 沈阳: 中国医科大学, 2019.
	LIAO F H. Study on the resistance and resistance genes of carbapenem resistant Klebsiella pneumoniae to tigecycline[D]. Shenyang: China Medical University, 2019. (in Chinese)
24	XU L , ZHOU Y , NIU S , et al. A novel inhibitor of monooxygenase reversed the activity of tetracyclines against tet(X3)/tet(X4)-positive bacteria[J]. EBioMedicine, 2022, 78, 103943.
25	许瑞, 刘建华, 胡功政, 等. 鸭源大肠杆菌3种tet基因的多重PCR检测[J]. 江西农业学报, 2011, 23 (3): 150- 152.
	XU R , LIU J H , HU G Z , et al. Multiplex PCR detection of three tet genes in duck derived Escherichia coli[J]. Journal of Jiangxi Agriculture, 2021, 23 (3): 150- 152.
26	SHENG Z K , HU F , WANG W , et al. Mechanisms of tigecycline resistance among Klebsiella pneumoniae clinical isolates[J]. Antimicrob Agents Chemother, 2014, 58 (11): 6982- 6985.
27	毛昳涵. 碳青霉烯耐药肺炎克雷伯菌院内流行及替加环素耐药机制研究[D]. 杭州: 浙江大学, 2019.
	MAO M H. In-hospital prevalence of carbapenem resistant Klebsiella pneumoniae and the mechanism of tigecycline resistance[D]. Hangzhou: Zhejiang University, 2019. (in Chinese)
28	郑雅卿. 耐碳青霉烯类肺炎克雷伯菌的IMP-4耐药基因LAMP检测及替加环素耐药检测和耐药机制研究[D]. 福州: 福建医科大学, 2017.
	ZHENG Y Q. Detection of IMP-4 resistance gene LAMP and tigecycline resistance detection and resistance mechanism of carbapenem resistant Klebsiella pneumoniae[D]. Fuzhou: Fujian Medicine University, 2017. (in Chinese)
29	TVRKEL , YILDIRIM T , YAZGAN B , et al. Relationship between antibiotic resistance, efflux pumps, and biofilm formation in extended-spectr um β-lactamase producing Klebsiella pneumoniae[J]. J Chemother, 2018, 30 (6-8): 354- 363.
30	HUANG J , ZHANG S , ZHAO Z , et al. Acquisition of a stable and transferable bla_NDM-5-positive plasmid with low fitness cost leading to ceftazidime/avibactam resistance in KPC-2-producing Klebsiella pneumoniae during treatment[J]. Front Cell Infect Microbiol, 2021, 11, 658070.
31	SPSSAU. 相关分析之各类相关系数汇总[Z]. SPSSAU, 2024. https://baijiahao.baidu.com/s?id=1789055704401470445&wfr=spider&for=pc. (2025-04-04)
	SPSSAU. Summary of various correlation coefficients for correlation analysis[Z]. SPSSAU, 2024. https://baijiahao.baidu.com/s?id=1789055704401470445&wfr=spider&for=pc. (2025-04-04).
32	张凯川, 王晋宇, 李守军, 等. 广东省羊源肺炎克雷伯菌遗传进化与毒力基因及耐药性分析[J]. 畜牧兽医学报, 2023, 54 (1): 328- 337. doi: 10.11843/j.issn.0366-6964.2023.01.030
	ZHANG K C , WANG J Y , LI S J , et al. Isolation, identification and biological characteristics of Klebsiella pneumoniae from sheep in Guangdong Province[J]. Acta Veterinaria et Zootechnica Sinica, 2023, 54 (1): 328- 337. doi: 10.11843/j.issn.0366-6964.2023.01.030
33	FERGADAKI S , RENIERIS G , MACHAIRAS N , et al. Efficacy of tigecycline alone or in combination for experimental infections by KPC carbapenemase-producing Klebsiella pneumoniae[J]. Int J Antimicrob Agents, 2021, 58 (3): 106384.
34	LI Y , KUMAR S , ZHANG L , et al. Characteristics of antibiotic resistance mechanisms and genes of Klebsiella pneumoniae[J]. Open Med (Wars), 2023, 18 (1): 20230707.
35	吴雪. 肺炎克雷伯菌生物膜与外排泵基因及药物敏感性相关关系[D]. 大连: 大连医科大学, 2020.
	WU X. Correlation between Klebsiella pneumoniae biofilm and efflux pump genes and drug susceptibility[D]. Dalian: Dalian Medical University, 2020. (in Chinese)
36	BENDER J K , KLARE I , FLEIGE C , et al. A nosocomial cluster of tigecycline-and vancomycin-resistant Enterococcus faecium isolates and the impact of rpsJ and tet(M) mutations on tigecycline resistance[J]. Microb Drug Resist, 2020, 26 (6): 576- 582.
37	XU Q , SHENG Z , HAO M , et al. RamA upregulates multidrug resistance efflux pumps AcrAB and OqxAB in Klebsiella pneumoniae[J]. Int J Antimicrob Agents, 2021, 57 (2): 106251.
38	HAN X , SHI Q , MAO Y , et al. Emergence of ceftazidime/avibactam and tigecycline resistance in carbapenem-resistant Klebsiella pneumoniae due to in-host microevolution[J]. Front Cell Infect Microbiol, 2021, 11, 757470.
39	KACZMAREK F M , DIB-HAJJ F , SHANG W , et al. High-level carbapenem resistance in a Klebsiella pneumoniae clinical isolate is due to the combination of bla(ACT-1) beta-lactamase production, porin OmpK35/36 insertional inactivation, and down-regulation of the phosphate transport porin phoe[J]. Antimicrob Agents Chemother, 2006, 50 (10): 3396- 3406.
40	SHI W , LI K , JI Y , et al. Carbapenem and cefoxitin resistance of Klebsiella pneumoniae strains associated with porin OmpK36 loss and DHA-1 β-lactamase production[J]. Braz J Microbiol, 2013, 44 (2): 435- 442.
41	KARAMPATAKIS T , TSERGOULI K , BEHZADI P . Carbapenem-resistant Klebsiella pneumoniae: virulence factors, molecular epidemiology and latest updates in treatment options[J]. Antibiotics (Basel), 2023, 12 (2): 234.
42	AL-QURAINI M , RIZVI M , AL-JABRI Z , et al. Assessment of in-vitro synergy of fosfomycin with meropenem, amikacin and tigecycline in whole genome sequenced extended and pan drug resistant Klebsiella Pneumoniae: Exploring a colistin sparing protocol[J]. Antibiotics (Basel), 2022, 11 (2): 153.
43	JIN X , CHEN Q , SHEN F , et al. Resistance evolution of hypervirulent carbapenem-Resistant Klebsiella pneumoniae ST11 during treatment with tigecycline and polymyxin[J]. Emerg Microbes Infect, 2021, 10 (1): 1129- 1136.

菌种编号 Strains number	种属来源 Species origin	分离地区 Isolated area	分离时间 Isolated time	序列类型 ST types	登录号 Accession number
KP30727	人	武汉大学中南医院	2021-12-17	ST15	SAMN43221293
KP30535	人	武汉大学中南医院	2021-12-17	ST11	SAMN43221298
KP30845	人	武汉大学中南医院	2021-12-17	ST11	SAMN43221295

抗菌药物 Antibiotic	判定标准 Judgment criteria			浓度 Concentration	质控范围 Quality control	参考文献 Reference
抗菌药物 Antibiotic	敏感 Sensitive	中介 Intermediate	耐药 Resistance	浓度 Concentration	质控范围 Quality control	参考文献 Reference
替加环素 Tigecycline	≤2	4	≥8	0.03~16.00	0.03~0.25	FDA，2016

引物名称 Primer name	引物序列(5′→3′) Sequences	产物/bp Products	参考文献 References
rpoB-F	AGGCGAATCCAGCTTGTTCAGC	147	^[19]
rpoB-R	TGACGTTGCATGTTCGCACCCATCA	147	^[19]
acrA-F	ATGTGACGATAAACCGGCTC	101	^[20]
acrA-R	CTGGCAGTTCGGTGGTTATT	101	^[20]
acrB-F	CGATAACCTGATGTACATGTCC	207	^[21]
acrB-R	CCGACAACCATCAGGAAGCT	207	^[21]
tolC-F	CTACAAACAGGCGGTGGTCT	170	^[22]
tolC-R	TGTTCAGCTCGTTGATCAGG	170	^[22]
oqxA-F	GACAGCGTCGCACAGAATG	850	^[23]
oqxA-R	GATCAGCGTGGCTTTGAACT	850	^[23]
oqxB-F	CGAAGAAAGACCTCCCTACCC	538
oqxB-R	GAACCCTGACCCAGTCCTAAA	538
tet(X4)-F	ATGGAAACCGGCTAATGGCT	195	^[24]
tet(X4)-R	TGTAGCGTTCGTCCCAATCG	195	^[24]
tetA-F	GCTACATCCTGCTTGCCTTC	210	^[25]
tetA-R	CATAGATCGCCGTGAAGAGG	210	^[25]
ramA-F	ATTTCCGCTCAGGTGATT	115	^[26]
ramA-R	GTTGCAGATGCCATTTCG	115	^[26]
ramR-F	CGCGCAATATCTGGAACAGC	292	^[27]
ramR-R	TCAAAGCCGAGGGCGATAAT	292	^[27]
rarA-F	ATTGCCCTCGGCTTTGAC	102
rarA-R	AACAGAGCGGCTGATACTCC	102
marA-F	GGAGATTGCGCAGAAGCTCA	157	^[28]
marA-R	GGATTCGCCAGGTACATTCG	157	^[28]
acrR-F	TGACAGCGAACCATTCGACA	126	本研究 This study
acrR-R	CATGTTCAGCAATCCGCTCG	126	本研究 This study
msbA-F	GGATCGCTCAGTGCTGCTAT	157
msbA-R	CATACCCATCATGTGGCCGA	157
kpnG-F	AAGGCTAAGACCCAACTGGC	244
kpnG-R	TGGCGTTGTACTGCTGGATT	244
kpnH-F	AACGCGCAGCAGATATACGA	276
kpnH-R	GCGAGAACTGGACAACCTGA	276
kdeA-F	GTTGTTCCCGTTATGTCTGGTGC	170	^[29]
kdeA-R	CCAGCAGCCACTGTAAAAACATGC	170	^[29]
kexD-F	ACCGGTTGCGCAATACCCTGA	184
kexD-R	CGTAATTGACGCCATCCCTG	184
kpnE-F	ATTGCTGAAATTACCGGCAC	172	^[29]
kpnE-R	AAATACCGATCCCTTCCCAC	172	^[29]
kpnF-F	ACAATGGCGATTGCCAGCCA	96	本研究 This study
kpnF-R	AAGTCCGGCACCCAGAAAAA	96	本研究 This study
Ompk37-F	CAACAACACCGAGACCTCCA	171	^[30]
Ompk37-R	GCATAGGTGTAGGAGTCGCC	171	^[30]
OmpA-F	AGACCGTTTAGCCAGGTTCG	208	本研究 This study
OmpA-R	GTCACGGCTGGTATCTACGG	208	本研究 This study

菌株 Stains	替加环素 TGC		替加环素+PAβN TGC+PAβN		MIC变化 MIC changes
菌株 Stains	MIC/(μg·mL^-1)	结果判定Judgment	MIC/(μg·mL^-1)	结果判定Judgment	MIC变化 MIC changes
ATCC13883	0.5	敏感	0.25	敏感	2
KP30845	4.0	中介	2.00	敏感	2
KP30535	8.0	耐药	2.00	敏感	4
KP30727	2.0	敏感	0.50	敏感	4

菌株 Strains	基因区域 Gene region	一致性/% Identity	突变 Mutation	核苷酸变化 Nucleotide change	耐药表型 Phenotype
KP30727	Ompk37	99.73	p.I70M	ATT>ATG	carbapenem
			p.I128M	ATT>ATG	carbapenem
	acrR	98.46	p.P161R	CCC>CGG	fluorquinolone
			p.G164A	GGC>GCC	fluorquinolone
			p.F172S	TTC>TCC	fluorquinolone
			p.R173G	CGA>GGG	fluorquinolone
			p.L195V	CTC>GTC	fluorquinolone
			p.F197I	TTT>ATT	fluorquinolone
P30727	acrR	98.46	p.K201M	AAG>ATG	fluorquinolone
	ramR	99.15	p.A19V	GCG>GTG	tigecycline
KP30535	Ompk37	99.50	p.I70M	ATT>ATG	carbapenem
			p.I128M	ATT>ATG	carbapenem
			p.N230G	AAC>GGC	carbapenem
			p.M233Q-Frameshift	undefined	carbapenem
	acrR	100.00	p.P161R	CGG>CGG	fluoroquinolone
			p.G164A	GGC>GCC	fluoroquinolone
			p.F172S	TTC>TCC	fluoroquinolone
			p.R173G	CGA>GGG	fluoroquinolone
		97.33	p.L195V	CTC>GTC	fluoroquinolone
			p.F197I	TTT>ATT	fluoroquinolone
			p.K201M	AAG>ATG	fluoroquinolone
KP30845	Ompk37	99.50	p.I70M	ATT>ATG	carbapenem
			p.I128M	ATT>ATG	carbapenem
			p.N230G	AAC>GGC	carbapenem
		100.00	p.M233Q-Frameshift	undefined	carbapenem
	acrR		p.P161R	CGG>CGG	fluoroquinolone
KP30845	acrR	100.00	p.G164A	GGC>GCC	fluoroquinolone
			p.F172S	TTC>TCC	fluoroquinolone
			p.R173G	CGA>GGG	fluoroquinolone
		97.33	p.L195V	CTC>GTC	fluoroquinolone
			p.F197I	TTT>ATT	fluoroquinolone
			p.K201M	AAG>ATG	fluoroquinolone
