非洲猪瘟病毒p30蛋白与CRM197的融合表达及对小鼠的免疫原性评价

doi:10.11843/j.issn.0366-6964.2024.11.038

摘要/Abstract

摘要：

非洲猪瘟是由非洲猪瘟病毒引起的一种急性、高传染性和致死性的传染病，对猪养殖业造成了巨大的影响。安全有效的疫苗和有效治疗药物的缺乏给非洲猪瘟防控带来了巨大的挑战。作者尝试设计一种融合蛋白以改善非洲猪瘟病毒p30的免疫原性。白喉毒素的无毒突变体CRM197已被成功地用作多糖-蛋白结合疫苗的载体蛋白，以增强多糖的免疫原性。本研究构建p30与CRM197催化结构域(A片段)的融合表达质粒，纯化后的重组蛋白和单独p30分别使用小鼠评价了其免疫原性。结果显示：通过原核表达与亲和层析纯化得到融合蛋白p30-CRM197(A)免疫小鼠后，较单独表达的p30其可以在更短的时间内激发起高水平针对p30的特异性IgG，并且在初次免疫后56 d后还能维持较高水平的淋巴细胞免疫活力。本研究结果表明，CRM197的A片段作为载体蛋白显著增强原核表达p30蛋白的免疫原性，其可作为非洲猪瘟亚单位疫苗的候选分子内佐剂。

关键词: 非洲猪瘟, CRM197, p30, 免疫原性

Abstract:

African swine fever is an acute, highly contagious and deadly infectious disease caused by the African swine fever virus, which has had a huge impact on the pig breeding industry. The lack of vaccines and effective therapeutic drugs has brought great challenges to the prevention and control of African swine fever. We tried to design a fusion protein to improve the immunogenicity of African swine fever virus p30. CRM197, a non-virulent mutant of diphtheria toxin, has been successfully used as a carrier protein in polysaccharide-protein conjugate vaccines to enhance the immunogenicity of polysaccharides. In this study, a fusion expression plasmid of p30 and CRM197 catalytic domain (A fragment) was constructed, and the immunogenicity of the purified recombinant protein and p30 alone were evaluated using mice. After immunizing mice with the fusion protein p30-CRM197(A) purified by prokaryotic expression and affinity chromatography, p30 alone could excite a high level of specific IgG against p30 in a shorter period of time, and maintain a high level of lymphocyte immune activity two months after the initial epidemic. The results of this study showed that the A fragment of CRM197 alone could significantly enhance the immunogenicity of prokaryotic expression p30 protein as a protein carrier, and it could be used as a candidate intramolecular adjuvant for African swine fever subunit vaccine.

Key words: African swine fever, CRM197, p30, immunogenicity

中图分类号:

S852.659.1

张琦, 董宁宁, 谈晓梅, 石正旺, 李娜, 朱雯琪, 汤傲星, 李传锋, 朱杰, 刘光清, 苏艳, 孟春春. 非洲猪瘟病毒p30蛋白与CRM197的融合表达及对小鼠的免疫原性评价[J]. 畜牧兽医学报, 2024, 55(11): 5230-5237.

Qi ZHANG, Ningning DONG, Xiaomei TAN, Zhengwang SHI, Na LI, Wenqi ZHU, Aoxing TANG, Chuanfeng LI, Jie ZHU, Guangqing LIU, Yan SU, Chunchun MENG. Fusion Expression of African Swine Fever Virus p30 Protein and CRM197 and Evaluation of Its Immunogenicity in Mice[J]. Acta Veterinaria et Zootechnica Sinica, 2024, 55(11): 5230-5237.

图/表 6

表 1

图 1

图 2

图 3

图 4

图 5

参考文献 23

1	ZHOU X T , LI N , LUO Y Z , et al. Emergence of African swine fever in China, 2018[J]. Transbound Emerg Dis, 2018, 65 (6): 1482- 1484. doi: 10.1111/tbed.12989
2	石建州, 何健, 刘阳坤, 等. 非洲猪瘟疫苗研究进展[J]. 中国兽医学报, 2022, 42 (5): 1057-1065, 1076.
	SHI J Z , HE J , LIU Y K , et al. Progress in development of vaccine against African swine fever[J]. Chinese Journal of Veterinary Medicine, 2022, 42 (5): 1057-1065, 1076.
3	王西西, 陈青, 吴映彤, 等. 非洲猪瘟疫苗研究进展[J]. 中国动物传染病学报, 2018, 26 (2): 89- 94.
	WANG X X , CHEN Q , WU Y T , et al. Recent progress on vaccine development against African swine fever[J]. Chinese Journal of Animal Infectious Diseases, 2018, 26 (2): 89- 94.
4	SÁNCHEZ-CORDÓN P J , MONTOYA M , REIS A L , et al. African swine fever: a re-emerging viral disease threatening the global pig industry[J]. Vet J, 2018, 233, 41- 48. doi: 10.1016/j.tvjl.2017.12.025
5	ARIAS M , DE LA TORRE A , DIXON L , et al. Approaches and perspectives for development of African swine fever virus vaccines[J]. Vaccines (Basel), 2017, 5 (4): 35. doi: 10.3390/vaccines5040035
6	RAMIREZ-MEDINA E , VUONO E , O'DONNELL V , et al. Differential effect of the deletion of African swine fever virus virulence-associated genes in the induction of attenuation of the highly virulent Georgia strain[J]. Viruses, 2019, 11 (7): 599. doi: 10.3390/v11070599
7	TEKLUE T , SUN Y , ABID M , et al. Current status and evolving approaches to African swine fever vaccine development[J]. Transbound Emerg Dis, 2020, 67 (2): 529- 542. doi: 10.1111/tbed.13364
8	GÓMEZ-PUERTAS P , RODRÍGUEZ F , OVIEDO J M , et al. The African swine fever virus proteins p54 and p30 are involved in two distinct steps of virus attachment and both contribute to the antibody-mediated protective immune response[J]. Virology, 1998, 243 (2): 461- 471. doi: 10.1006/viro.1998.9068
9	BARDERAS M G , RODRÍGUEZ F , GÓMEZ-PUERTAS P , et al. Antigenic and immunogenic properties of a chimera of two immunodominant African swine fever virus proteins[J]. Arch Virol, 2001, 146 (9): 1681- 1691. doi: 10.1007/s007050170056
10	BRÖKER M , COSTANTINO P , DETORA L , et al. Biochemical and biological characteristics of cross-reacting material 197 (CRM₁₉₇), a non-toxic mutant of diphtheria toxin: use as a conjugation protein in vaccines and other potential clinical applications[J]. Biologicals, 2011, 39 (4): 195- 204. doi: 10.1016/j.biologicals.2011.05.004
11	MALITO E , BURSULAYA B , CHEN C , et al. Structural basis for lack of toxicity of the diphtheria toxin mutant CRM197[J]. Proc Natl Acad Sci U S A, 2012, 109 (14): 5229- 5234. doi: 10.1073/pnas.1201964109
12	陈柯. 白喉毒素突变体CRM197的研究及应用[J]. 微生物学免疫学进展, 2022, 50 (3): 70- 76.
	CHEN K . Research and application of diphtheria toxin mutant CRM197[J]. Progress in Microbiology and Immunology, 2022, 50 (3): 70- 76.
13	GRUBER W C , SCOTT D A , EMINI E A . Development and clinical evaluation of Prevnar 13, a 13-valent pneumocococcal CRM₁₉₇ conjugate vaccine[J]. Ann N Y Acad Sci, 2012, 1263, 15- 26. doi: 10.1111/j.1749-6632.2012.06673.x
14	DAGAN R , POOLMAN J , SIEGRIST C A . Glycoconjugate vaccines and immune interference: a review[J]. Vaccine, 2010, 28 (34): 5513- 5523. doi: 10.1016/j.vaccine.2010.06.026
15	TOBIAS J , JASINSKA J , BAIER K , et al. Enhanced and long term immunogenicity of a Her-2/neu multi-epitope vaccine conjugated to the carrier CRM197 in conjunction with the adjuvant Montanide[J]. BMC Cancer, 2017, 17 (1): 118. doi: 10.1186/s12885-017-3098-7
16	TANG X Z , YU W L , SHEN L J , et al. Conjugation with 8-arm PEG and CRM₁₉₇ enhances the immunogenicity of SARS-CoV-2 ORF8 protein[J]. Int Immunopharmacol, 2022, 109, 108922. doi: 10.1016/j.intimp.2022.108922
17	GUTTORMSEN H K , SHARPE A H , CHANDRAKER A K , et al. Cognate stimulatory B-cell-T-cell interactions are critical for T-cell help recruited by glycoconjugate vaccines[J]. Infect Immun, 1999, 67 (12): 6375- 6384. doi: 10.1128/IAI.67.12.6375-6384.1999
18	WANG K H , ZHOU L Z , ZHANG X , et al. Hepatitis E vaccine candidate harboring a non-particulate immunogen of E2 fused with CRM197 fragment A[J]. Antiviral Res, 2019, 164, 154- 161. doi: 10.1016/j.antiviral.2019.02.013
19	LIU L Q , CHEN T T , ZHOU L Z , et al. A bacterially expressed SARS-CoV-2 receptor binding domain fused with cross-reacting material 197 a-domain elicits high level of neutralizing antibodies in mice[J]. Front Microbiol, 2022, 13, 854630. doi: 10.3389/fmicb.2022.854630
20	赵旭阳, 靳家鑫, 路闻龙, 等. 非洲猪瘟病毒免疫逃逸分子机制研究进展[J]. 畜牧兽医学报, 2022, 53 (7): 2074- 2082. doi: 10.11843/j.issn.0366-6964.2022.07.005
	ZHAO X Y , JIN J X , LU W L , et al. Advances in the molecular mechanism of immune escape of African swine fever virus[J]. Acta Veterinaria et Zootechnica Sinica, 2022, 53 (7): 2074- 2082. doi: 10.11843/j.issn.0366-6964.2022.07.005
21	黄剑, 李国新, 童光志. 非洲猪瘟的流行病学及疫苗研究新进展[J]. 中国动物传染病学报, 2022, 30 (4): 197- 205.
	HUANG J , LI G X , TONG G Z . Epidemiology of African swine fever and progress in vaccine research[J]. Chinese Journal of Animal Infectious Diseases, 2022, 30 (4): 197- 205.
22	GÓMEZ-PUERTAS P , RODRÍGUEZ F , OVIEDO J M , et al. Neutralizing antibodies to different proteins of African swine fever virus inhibit both virus attachment and internalization[J]. J Virol, 1996, 70 (8): 5689- 5694. doi: 10.1128/jvi.70.8.5689-5694.1996
23	徐娅玲. ASFV亚单位疫苗和多肽疫苗免疫效力的评估[D]. 贵阳: 贵州大学, 2022.
	XU Y L. Assessment of the immune efficacy of ASFV subunit vaccines and peptide vaccines[D]. Guiyang: Guizhou University, 2022. (in Chinese)

目的基因 Target gene	寡核苷酸序列(5′→3′) Oligonucleotide sequence
p30	F: GCCATGGCTGATATCGGATCCATGAAAATGGAGGTCATC
p30	R: TCCACCACCACCAGATCCACCACCACCTTTTTTTTTTAAAAGTTTAATAAC
CRM197(A)	F: GGTGGTGGATCTGGTGGTGGTGGATCTATGGGCGCGGATGATGTG
CRM197(A)	R: CTCGAGTGCGGCCGCAAGCTTGCGCACGCGGTTGCCCGC
