稳定表达猪瘟病毒NS3-NS4A和NS3pro-NS4A蛋白巨噬细胞系的构建及蛋白质组学分析

doi:10.11843/j.issn.0366-6964.2025.11.040

Abstract

Abstract:

The purpose of this study is to better explore the interaction between host innate immunity and classical swine fever virus (CSFV) by constructing a stable expressing CSFV NS3/NS4A and pCMV-CBH-GFP-2A-Puro-CSFV NS3^pro-NS4A, pCMV-CBH-GFP-2A-Puro-CSFV NS3-NS4A and pCMV-CBH-GFP-2A-Puro recombinant expression vector were separately infected with HEK-293T cells packaged out of the lentivirus. Then, packaged lentivirus was used to infect porcine alveolar macrophages (3D4/21), monoclonal screening of infected cell lines was performed to obtain stable cell lines, and the protein expression of stable cell lines was verified by Western blot. Proteomic analysis was conducted on it to screen out the interacting proteins of MAPK and PI3K pathways, and functional analysis was carried out. Detection of CDK4, CDC37, CASP3, IKBKG, and NFκB1 Protein Expression Levels via Western blot Analysis. The results showed that the amino acid sequences of NS3-NS4A and NS3^pro-NS4A lentiviral vectors constructed by MegAlign analysis were correct without frameshift. After the recombinant expression vector infected 293T cells for 24 hours, the infection efficiency could reach more than 90%, the lentvirus was successfully packaged, and the stable expression of CSFV NS3-NS4A and NS3^pro-NS4A macrophage cell lines were successfully obtained by Western blot analysis. Through proteomic analysis, 11 up-regulated and 24 down-regulated proteins in the MAPK and PI3K pathways were screened out in the NS3-NS4A/mock group. Western blot analysis revealed that CSFV NS3-NS4A significantly reduced the expression of CASP3, NFκB1, and IKBKG in the MAPK pathway, as well as CDK4 and CDC37 in the PI3K pathway. In this study, 3D4/21 cell lines stably expressing NS3-NS4A and NS3^pro-NS4A proteins were successfully constructed, and conducted functional analysis on the key proteins screened by proteomics, which provides a material basis for studying the mechanism of CSFV NS3-NS4A regulating the host innate immune responses.

Key words: classical swine fever virus, NS3-NS4A, NS3^pro-NS4A, porcine alveolar macrophages, stably expressing

CLC Number:

S852.4

ZHENG Xiaoru, WANG Yidan, ZHANG Lihong, YANG Yingying, ZHAO Xinru, LI Min, HUANG Juan, ZHANG Qiaoya, CAO Zhi. Construction and Proteomic Analysis of Macrophage Cell Lines Stably Expressing NS3-NS4A and NS3^pro-NS4A of Classical Swine Fever Virus[J]. Acta Veterinaria et Zootechnica Sinica, 2025, 56(11): 5839-5851.

Figures/Tables 10

Table 1

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Table 2

Table 3

Fig. 7

References 28

1	LI X W , SONG Y W , WANG X Y , et al. The regulation of cell homeostasis and antiviral innate immunity by autophagy during classical swine fever virus infection[J]. Emerg Microbes Infect, 2023, 12 (1): 2164217. doi: 10.1080/22221751.2022.2164217
2	LI W H , ZHANG Z L , ZHANG L L , et al. Antiviral role of serine incorporator 5 (SERINC5) proteins in classical swine fever virus infection[J]. Front Microbiol, 2020, 11, 17. doi: 10.3389/fmicb.2020.00017
3	NING P B , ZHOU Y L , LIANG W L , et al. Different RNA splicing mechanisms contribute to diverse infective outcome of classical swine fever viruses of differing virulence: insights from the deep sequencing data in swine umbilical vein endothelial cells[J]. PeerJ, 2016, 4, e2113. doi: 10.7717/peerj.2113
4	LI S , WANG J , YANG Q , NAVEED A M , et al. Complex virus-host interactions involved in the regulation of classical swine fever virus replication: A minireview[J]. Viruses, 2017, 9 (7): 171. doi: 10.3390/v9070171
5	SUN J F , LI J Y , LI L M , et al. Classical swine fever virus NS5A protein antagonizes innate immune response by inhibiting the NF-xB signaling[J]. Virol Sin, 2023a, 38, 900- 910. doi: 10.1016/j.virs.2023.09.002
6	SUN L D , NIU J Q , ZHANG J S , et al. Thermostable T cell multiepitope nanoparticle antigens inducing potent immune responses against the swine fever virus[J]. Acs Infect Dis, 2023b, 9, 2358- 2368. doi: 10.1021/acsinfecdis.3c00506
7	BORDON Y . Disturbance of cytoskeleton primes RIG-I-like receptors[J]. Nat Rev Immunol, 2022, 22, 654- 655.
8	CAO T , LI X Y , XU Y H , et al. N^pro of Classical swine fever virus suppresses type Ⅲ interferon production by inhibiting IRF1 expression and its nuclear translocation[J]. Viruses-Basel, 2019a, 11, 18.
9	WALTHER T , BRUHN B , ISKEN O , et al. A novel NS3/4A protease dependent cleavage site within pestiviral NS2[J]. J Gen Virol, 2021, 102 (10): 119- 128.
10	FELLENBERG J , DUBRAU D , ISKEN O , et al. Packaging defects in pestiviral NS4A can be compensated by mutations in NS2 and NS3[J]. J Virol, 2023, 97 (9): e0057223. doi: 10.1128/jvi.00572-23
11	TAUTZ N , KAISER A , THIEL H J . NS3 serine protease of bovine viral diarrhea virus: characterization of active site residues, NS4A cofactor domain, and protease-cofactor interactions[J]. Virology, 2000, 273 (2): 351- 63. doi: 10.1006/viro.2000.0425
12	DUBRAN D , SCHWINDT S , KLEMENS O , et al. Determination of critical requirements for classical swine fever virus NS2-3-independent virion formation[J]. J Virol, 2019, 93 (18): e00679- 00619.
13	ABDULLAH M , MCWHIRTER S M , SUO Z C . Modulation of kinase activities in vitro by hepatitis C virus protease NS3/NS4A mediated-cleavage of key immune modulator kinases[J]. Cells, 2023, 12, 20.
14	李易聪, 蒲飞洋, 冯茜莉, 等. 牛病毒性腹泻病毒蛋白的免疫学特性以及相关疫苗研究进展[J]. 畜牧兽医学报, 2023, 54 (4): 1381- 1391. doi: 10.11843/j.issn.0366-6964.2023.04.004
	LI Y C , PU F Y , FENG X L , et al. Research progress on immunological characteristics of bovine viral diarrhea virus protein and vaccines[J]. Acta Veterinaria et Zootechnica Sinica, 2023, 54 (4): 1381- 1391. doi: 10.11843/j.issn.0366-6964.2023.04.004
15	FAN S Q , WU K K , LUO C W , et al. Dual NDP52 function in persistent CSFV infection[J]. Front Microbiol, 2020, 10, 13.
16	LAMOTHE-REYES Y , FIGUEROA M , SANCHEZ O . Host cell factors involved in classical swine fever virus entry[J]. Vet Res, 2023, 54 (1): 115. doi: 10.1186/s13567-023-01238-x
17	GVUONO E , RAMIREZ-MEDINA E , SILVA E , et al. Classical swine fever virus structural glycoprotein E2 interacts with host protein ACADM during the virus infectious cycle[J]. Viruses, 2023, 15 (5): 1036. doi: 10.3390/v15051036
18	王向鹏, 魏蕊芳, 肖书奇, 等. 慢病毒载体介导稳定表达CD163的PAM细胞系的建立及对PRRSV感染的研究[J]. 畜牧兽医学报, 2013, 44 (11): 1797- 1804. doi: 10.11843/j.issn.0366-6964.2013.11.014
	WANG X P , WEI R F , XIAO S Q , et al. Establishment of a Lentivirus-mediated stable CD163-expressing PAM cell line and research on PRRSV infection[J]. Journal of Animal Husbandry and Veterinary Medicine, 2013, 44 (11): 1797- 1804. doi: 10.11843/j.issn.0366-6964.2013.11.014
19	方鑫玉, 周磊, 杨汉春. 猪繁殖与呼吸综合征病毒受体CD163的研究进展[J]. 中国兽医杂志, 2024, 60 (12): 99- 105.
	FANG X Y , ZHOU L , YANG H C . Research progress on CD163, the receptor of porcine reproductive and respiratory syndrome virus[J]. Chinese Veterinary Science, 2024, 60 (12): 99- 105.
20	周峰, 赵军, 常洪涛, 等. 稳定表达CD163的PAM细胞系的建立[C]. 中国畜牧兽医学会动物传染病学分会, 2015: 2.
	ZHOU F, ZHAO J, CHANG H T, et al. Establishment of PAM cell lines stably expressing CD163[C]. Society of Animal Infectious Diseases, Chinese Association of Animal Husbandry and Veterinary Medicine, 2015: 2. (in Chinese)
21	DIEP N , HAYAKAWA-SUGAYA Y , ISHIKAWA S . Establishment of an immortalized porcine alveolar macrophage cell line that supports efficient replication of porcine reproductive and respiratory syndrome viruses[J]. Pathogens, 2024, 13 (12): 1026. doi: 10.3390/pathogens13121026
22	刘元杰, 徐璐, 朱元源, 等. 猪瘟病毒C株表位突变毒株的构建及拯救[J]. 畜牧兽医学报, 2024, 55 (2): 698- 705. doi: 10.11843/j.issn.0366-6964.2024.02.027
	LIU Y J , XU L , ZHU Y Y , et al. Construction and rescue of epitope mutant of swine fever virus C strain[J]. Journal of Animal Husbandry and Veterinary Medicine, 2024, 55 (2): 698- 705. doi: 10.11843/j.issn.0366-6964.2024.02.027
23	荆扬, 王玉淼, 李洋, 等. 稳定表达PRRSV M蛋白的MARC-145ORF6细胞系的构建及其对PRRSV增殖的影响[J]. 畜牧兽医学报, 2024, 55 (3): 1159- 1169. doi: 10.11843/j.issn.0366-6964.2024.03.028
	JING Y , WANG Y M , LI Y , et al. Construction of MARC-145ORF6 cell line stably overexpressing PRRSV M protein and its effect on PRRSV proliferation[J]. Acta Veterinaria et Zootechnica Sinica, 2024, 55 (3): 1159- 1169. doi: 10.11843/j.issn.0366-6964.2024.03.028
24	ALBAMAZ J D , KITE J , OLIVEIRA M , et al. Quantitative proteomics defines mechanisms of antiviral defence and cell death during modified vaccinia Ankara infection[J]. Nat Commun, 2023, 14 (1): 8134. doi: 10.1038/s41467-023-43299-8
25	蔡彬祥, 於子鼎, 曾显成, 等. 猪瘟病毒与宿主天然免疫系统的相互作用[J]. 微生物学通报, 2017, 44 (12): 2997- 3006.
	CAI B X , YU Z A , ZENG X C , et al. Interaction between classical swine fever virus and host innate immune system[J]. Microbiology Bulletin, 2017, 44 (12): 2997- 3006.
26	PRESTI D , QUAQUARINI E . The PI3K/AKT/mTOR and CDK4/6 pathways in endocrine resistant HR+/HER2-metastatic breast cancer: biological mechanisms and new treatments[J]. Cancers, 2019, 11 (9): 1242. doi: 10.3390/cancers11091242
27	ESKANDARI E , NEGRI G L , TAN S , et al. Dependence of human cell survival and proliferation on the CASP3 prodomain[J]. Cell Death Discov, 2024, 10, 63.
28	JELLUSOVA J , RICKERT R C . The PI3K pathway in B cell metabolism[J]. Crit Rev Biochem Mol Biol, 2016, 51 (5): 359- 378. doi: 10.1080/10409238.2016.1215288

Primer名称 Primer name	序列(5′→3′) Sequence
2-3-F1	GCTCTAGAATGGGAAAGATAGATGGCGG
2-3-R1	CAAACGGCAGGCCCTCTAAGCACCCAGC
2-3-F2	GCTGGGTGCTTAGAGGGCCTGCCGTTTG
2-3-R2	ATAAGAATGCGGCCGCTCATAGACCAACTAC
2B-3^pro-F1	GCTCTAGAATGGAAGGGGTATACCTT
2B-3^pro-R2	ATAAGAATGCGGCCGCTCAGTAGCAAGGGTT
3-4A-F1	GCTCTAGAATGGGGCCTGCCGTTTG
3-4A-R1	TTCTCAGCTGTTGATAGACCAACTACTT
3-4A-F2	AAGTAGTTGGTCTATCAACAGCTGAGAA
3-4A-R2	ATAAGAATGCGGCCGCTCATAGCTCCTTCAA
3^pro-4A-R1	TTCTCAGCTGTTGAGTAGCAAGGGTTAT
3^pro-4A-F2	ATAACCCTTGCTACTCAACAGCTGAGAA

通路 Pathway	项目 Item	蛋白序号 Protein No.	蛋白名称 Protein name	基因 Gene	NCBI蛋白登录号 NCBl protein accession No.		置信度/% Max identity
通路 Pathway	项目 Item	蛋白序号 Protein No.	蛋白名称 Protein name	基因 Gene	人 Human	猪 Pig	置信度/% Max identity
MAPK	上调蛋白 Up-regulated protein	1	phospholipase A2 group IVA	PLA2G4A	NP_001298122.2	XP_020919484.1	83
		2	amphiregulin	AREG	NP_001648.1	NP_999541.1	90
		3	tumor protein p53	P53	NP_000537.3	NP_998989.3	99
	下调蛋白 Down-regulated protein	4	tumor protein p53	P53	NP_000537.3	NP_998989.3	99
		5	growth factor receptor bound protein 2	GRB2	NP_002077.1	NP_001131100.1	98
		6	TNFRSF1A associated via death domain	TRADD	NP_001310481.1	XP_020949709.1	99
		7	TAO kinase 3	TAOK3	NP_001333416.1	XP_001924435.2	95
		8	serine/threonine kinase 3	STK3	NP_001243241.1	XP_005655407.3	93
		9	stathmin 1	STMN1	NP_001138926.1	XP_005665169.1	81
		10	protein phosphatase, Mg²⁺/Mn²⁺ dependent 1B	PPM1B	NP_001028729.1	XP_003125227.2	91
		11	mitogen-activated protein kinase kinase 4	MAP2K4	NP_001268364.1	XP_020923549.1	93
		12	inhibitor of nuclear factor kappa B kinase regulatory subunit gamma	IKBKG	NP_001093326.2	NP_001106524.1	96
		13	amphiregulin	AREG	NP_001648.1	NP_999541.1	90
		14	nuclear factor kappa B subunit 1	NFKB1	NP_001158884.1	NP_001041697.1	90
		15	caspase 3	CASP3	NP_001341706.1	NP_999296.1	91

通路 Pathway	项目 Item	蛋白序号 Protein No.	蛋白名称 Protein name	基因 Gene	NCBI蛋白登录号 NCBl protein accession No.		置信度/% Max identity
通路 Pathway	项目 Item	蛋白序号 Protein No.	蛋白名称 Protein name	基因 Gene	人 Human	猪 Pig	置信度/% Max identity
P13K	上调蛋白 Up-regulated protein	1	integrin subunit beta 5	ITGB5	NP_001341693.1	NP_001233598.1	99
		2	BCL2 like 1	BCL2L1	NP_001182.1	NP_999450.1	99
		3	phosphoenolpyruvate carboxykinase 2, mitochondrial	PCK2	NP_001018083.2	NP_001155225.1	96
		4	integrin subunit beta 5	ITGB5	NP_001341693.1	NP_001233598.1	99
		5	thrombospondin 4	THBS4	NP_001293141.1	XP_020940149.1	95
		6	amphiregulin	AREG	NP_001648.1	NP_999541.1	90
		7	tumor protein p53	P53	NP_000537.3	NP_998989.3	99
		8	collagen type Ⅵ alpha 2 chain	COL6A2	NP_001840.3	XP_020938158.1	93
	下调蛋白 Down-regucated protein	9	tumor protein p53	P53	NP_000537.3	NP_998989.3	99
		10	collagen type Ⅵ alpha 2 chain	COL6A2	NP_001840.3	XP_020938158.1	93
		11	cyclin dependent kinase 4	CDK4	NP_000066.1	NP_001116569.1	98
		12	growth factor receptor bound protein 2	GRB2	NP_002077.1	NP_001131100.1	98
		13	protein tyrosine kinase 2	PTK2	NP_001186578.1	XP_020944510.1	96
		14	protein phosphatase 2 regulatory subunit B’alpha	PPP2R5A	NP_001186685.1	NP_001093662.1	99
		15	heat shock protein 90 alpha family class B member 1	HSP90AB1	NP_001258898.1	NP_001231362.1	99
		16	cell division cycle 37, HSP90 cochaperone	CDC37	NP_008996.1	NP_001116568.1	99
		17	eukaryotic translation initiation factor 4B	EIF4B	NP_001287750.1	XR_002343952.1	93
		18	inhibitor of nuclear factor kappa B kinase regulatory subunit gamma	IKBKG	NP_001093326.2	NP_001106524.1	96
		19	amphiregulin	AREG	NP_001648.1	NP_999541.1	90
		20	nuclear factor kappa B subunit 1	NFKB1	NP_001158884.1	NP_001041697.1	90
		21	thrombospondin 1	THBS1	NP_003237.2	NP_001231465.1	90
