弓形虫PRU株速殖子感染小鼠产生包囊的试验研究

doi:10.11843/j.issn.0366-6964.2024.10.033

摘要/Abstract

摘要：

旨在获得弓形虫包囊，并对包囊传代保种，将其作为弓形虫慢性感染相关试验研究的感染性材料。本研究用四组不同数量的PRU株速殖子腹腔接种KM、ICR、BALB/c、C57BL/6四个品系小鼠，感染40 d后检测存活小鼠血清中抗体，取血清阳性小鼠各组织检查并分离包囊；以包囊灌胃感染不同品系小鼠，探究包囊传代剂量及最佳的传代小鼠品系。结果成功在感染低剂量的C57BL/6小鼠脑组织内分离得到包囊。包囊传代ICR小鼠死亡率低，且脑内成囊数显著多于其他品系小鼠(P < 0.05)。C57BL/6小鼠腹腔接种10~50个弓形虫速殖子可存活并在脑内形成包囊；以20~50个弓形虫包囊灌胃感染ICR小鼠，可扩增得到大量包囊。

关键词: PRU株, 速殖子, 包囊, 慢性感染, 包囊传代, 小鼠模型

Abstract:

This experiment was designed to obtain Toxoplasma cysts, which are often used as infectious materials in experimental studies related to chronic infection of Toxoplasma gondii, and to search for the most suitable mouse model for cysts passage. In this study, mice with KM, ICR, BALB/c and C57BL/6 strains were intraperitoneally inoculated with different numbers of tachyzoites of PRU strains. After 40 days of infection, antibodies in the serum of surviving mice were detected, and cysts were examined and isolated from the tissues of seropositive mice. Different strains of mice were infected by cyst intragastric administration to explore the cysts passage dose and the best passage mouse model. We successfully isolated cysts from the brains of C57BL/6 mice infected with low doses of Toxoplasma tachyzoites. When passing cysts, ICR mice had low mortality and significantly more cysts in the brain than other strains (P < 0.05). C57BL/6 mice can survive and form cysts in the brain when 10-50 tachyzoites are intraperitoneally inoculated; A larger number of toxoplasma cysts could be obtained by intragastric infecting ICR mice with 20-50 cysts.

Key words: PRU strain, tachyzoite, cysts, chronic infection, cyst passage, mouse model

中图分类号:

S852.72

李瑞芳, 张曼玉, 孙卿, 杜晶莹, 蒋蔚, 李增强, 夏炉明, 王权. 弓形虫PRU株速殖子感染小鼠产生包囊的试验研究[J]. 畜牧兽医学报, 2024, 55(10): 4620-4629.

Ruifang LI, Manyu ZHANG, Qing SUN, Jingying DU, Wei JIANG, Zengqiang LI, Luming XIA, Quan WANG. Experimental Study on the Production of Cysts in Mice Infected with Toxoplasma gondii Tachyzoites of PRU Strain[J]. Acta Veterinaria et Zootechnica Sinica, 2024, 55(10): 4620-4629.

图/表 14

表 1

表 2

表 3

表 4

表 5

图 1

图 2

图 3

图 4

图 5

图 6

表 6

表 7

图 7

参考文献 31

1	LIU Q , WANG Z D , HUANG S Y , et al. Diagnosis of toxoplasmosis and typing of Toxoplasma gondii[J]. Parasit Vectors, 2015, 8, 292. doi: 10.1186/s13071-015-0902-6
2	DUBEY J P . Advances in the life cycle of Toxoplasma gondii[J]. Int J Parasitol, 1998, 28 (7): 1019- 1024. doi: 10.1016/S0020-7519(98)00023-X
3	DUBEY J P , LINDSAY D S , SPEER C A . Structures of Toxoplasma gondii tachyzoites, bradyzoites, and sporozoites and biology and development of tissue cysts[J]. Clin Microbiol Rev, 1998, 11 (2): 267- 299. doi: 10.1128/CMR.11.2.267
4	SANCHEZ S G , BESTEIRO S . The pathogenicity and virulence of Toxoplasma gondii[J]. Virulence, 2021, 12 (1): 3095- 3114. doi: 10.1080/21505594.2021.2012346
5	BAHREINI M S , NOHTANI M , SALEMI A M , et al. Introduction of protocols for mass production of Toxoplasma gondii tachyzoites of the genotype Ⅱ PRU strain[J]. Anim Models Exp Med, 2021, 4 (3): 278- 282. doi: 10.1002/ame2.12174
6	李祎, 李星, 周冰洁, 等. 三株弓形虫对昆明鼠致病性的比较研究[J]. 畜牧兽医学报, 2017, 48 (10): 1976- 1982. doi: 10.11843/j.issn.0366-6964.2017.10.021
	LI Y , LI X , ZHOU B J , et al. Pathogenicity comparison of three Toxoplasma gondii strains to kunming mice[J]. Acta Veterinaria et Zootechnica Sinica, 2017, 48 (10): 1976- 1982. doi: 10.11843/j.issn.0366-6964.2017.10.021
7	CHEN M , YANG P , XIN Z X , et al. Toxoplasma gondii gra5 deletion mutant protects hosts against Toxoplasma gondii infection and breast tumors[J]. Front Immunol, 2023, 14, 1173379. doi: 10.3389/fimmu.2023.1173379
8	TIAN X W , YANG Z K , WAN G M , et al. Vaccination with recombinant Toxoplasma gondii bradyzoite-formation deficient 1(rTgBFD1) antigen provides partial protective immunity against chronic T. gondii infection[J]. Front Vet Sci, 2022, 9, 957479. doi: 10.3389/fvets.2022.957479
9	TOMITA T , BZIK D J , MA Y F , et al. The Toxoplasma gondii cyst wall protein CST1 is critical for cyst wall integrity and promotes bradyzoite persistence[J]. PLoS Pathog, 2013, 9 (12): e1003823. doi: 10.1371/journal.ppat.1003823
10	BAUMAN N , ILIC' A , LIJESKIC' O , et al. Computational image analysis reveals the structural complexity of Toxoplasma gondii tissue cysts[J]. PLoS One, 2020, 15 (8): e0234169. doi: 10.1371/journal.pone.0234169
11	吴梦云, 蔡茹, 李伊凡, 等. 慢性感染阶段弓形虫包囊在小鼠脑组织的动态病理变化[J]. 安徽医科大学学报, 2023, 58 (2): 184- 188.
	WU M Y , CAI R , LI Y F , et al. Dynamic pathological changes of Toxoplasma cysts in mouse brain during chronic infection[J]. Acta Universitatis Medicinalis Anhui, 2023, 58 (2): 184- 188.
12	陈慧娴, 陈雅婕, 王先梅, 等. 弓形虫和新孢子虫交叉反应抗原MIC7A对小鼠的免疫保护效力分析[J]. 畜牧兽医学报, 2022, 53 (7): 2300- 2306. doi: 10.11843/j.issn.0366-6964.2022.07.026
	CHEN H X , CHEN Y J , WANG X M , et al. Identification of the cross-reacting antigen MIC17A of Toxoplasma gondii and Neospora caninum and the study of its cross-immune protective efficacy in mice[J]. Acta Veterinaria et Zootechnica Sinica, 2022, 53 (7): 2300- 2306. doi: 10.11843/j.issn.0366-6964.2022.07.026
13	汪涛, 汤自豪. 弓形虫病: 速殖子、包囊和卵囊的传播[J]. 中国人兽共患病学报, 2012, 28 (11): 1133- 1136. doi: 10.3969/cjz.j.issn.1002-2694.2012.11.016
	WANG T , TANG Z H . Toxoplasmosis: the spread of tachyzoites, cysts and oocysts[J]. Chinese Journal of Zoonoses, 2012, 28 (11): 1133- 1136. doi: 10.3969/cjz.j.issn.1002-2694.2012.11.016
14	刘俊燕, 杨秀珍, 吴增强, 等. 弓形虫慢性感染鼠形成包囊的实验研究[J]. 天津医科大学学报, 2001, 7 (2): 176-177, 198. doi: 10.3969/j.issn.1006-8147.2001.02.011
	LIU J Y , YANG X Z , WU Z Q , et al. Study on cyst formation of toxoplAsma gondii in chronically infected mice[J]. Journal of Tianjin Medical University, 2001, 7 (2): 176-177, 198. doi: 10.3969/j.issn.1006-8147.2001.02.011
15	CHRISTIANSEN C , MAUS D , HOPPENZ E , et al. In vitro maturation of Toxoplasma gondii bradyzoites in human myotubes and their metabolomic characterization[J]. Nature Communications, 2022, 13 (1): 1168. doi: 10.1038/s41467-022-28730-w
16	DUBEY J P . Re-examination of resistance of Toxoplasma gondii tachyzoites and bradyzoites to pepsin and trypsin digestion[J]. Parasitology, 1998, 116 (Pt 1): 43- 50.
17	ZHOU C X , GAO M , HAN B , et al. Quantitative peptidomics of mouse brain after infection with cyst-forming Toxoplasma gondii[J]. Front Immunol, 2021, 12, 681242. doi: 10.3389/fimmu.2021.681242
18	王权, 王巧全, 潘淑娟, 等. 动物源性食品中弓形虫Nested PCR-RFLP分子检测技术的建立[J]. 中国兽医寄生虫病, 2007, 15 (6): 1- 7. doi: 10.3969/j.issn.1674-6422.2007.06.001
	WANG Q , WANG Q Q , PAN S J , et al. Establishment of nested PCR-RFLP for detecting Toxoplasma gondii in animal-derived food[J]. Chinese Journal of Veterinary Parasitology, 2007, 15 (6): 1- 7. doi: 10.3969/j.issn.1674-6422.2007.06.001
19	张爱民, 陆琴, 杨惠珍. 弓形虫脑组织包囊两种分离法的比较[J]. 中国人兽共患病杂志, 1996, 12 (3): 39- 40.
	ZHANG A M , LU Q , YANG H Z . Comparison of two methods of isolation of Toxoplasma gondii cysts in brain tissue[J]. Chinese Journal of Zoonoses, 1996, 12 (3): 39- 40.
20	李亚飞, 王寒, 潘长旺, 等. PRU株弓形虫包囊感染小鼠模型的建立[J]. 中国人兽共患病学报, 2010, 26 (8): 769- 771. doi: 10.3969/j.issn.1002-2694.2010.08.013
	LI Y F , WANG H , PAN C W , et al. Model establishment on mice infected with Toxoplasma gondii cysts of PRU strain[J]. Chinese Journal of Zoonoses, 2010, 26 (8): 769- 771. doi: 10.3969/j.issn.1002-2694.2010.08.013
21	NEDIŞAN M E , GYÖRKE A , ŞTEFǍNUŞ C L , et al. Experimental infection with Toxoplasma gondii in broiler chickens (Gallus domesticus): seroconversion, tissue cyst distribution, and prophylaxis[J]. Parasitol Res, 2021, 120 (2): 593- 603. doi: 10.1007/s00436-020-06984-x
22	王林, 霍星星, 陈兆武, 等. 刚地弓形虫China 1基因型成囊株在小鼠体内的动态分布[J]. 中国寄生虫学与寄生虫病杂志, 2012, 30 (3): 179- 183.
	WANG L , HUO X X , CHEN Z W , et al. Kinetic distribution of cyst-forming Chinese isolate of Toxoplasma gondii in mice[J]. Chinese Journal of Parasitology and Parasitic Diseases, 2012, 30 (3): 179- 183.
23	周永华, 岑伟家, 王坚武, 等. 不同品系小鼠对弓形虫易感性的初步研究[J]. 中国人兽共患病杂志, 1991, 7 (5): 21- 22.
	ZHOU Y H , CEN W J , WANG J W , et al. Study on susceptibility to infectoin with Toxoplasma gondii in different strains of mice[J]. Chinese Journal of Zoonoses, 1991, 7 (5): 21- 22.
24	GATKOWSKA J , HISZCZYNSKA-SAWICKA E , KUR J , et al. Toxoplasma gondii: an evaluation of diagnostic value of recombinant antigens in a murine model[J]. Exp Parasitol, 2006, 114 (3): 220- 227. doi: 10.1016/j.exppara.2006.03.011
25	万民生, 徐克继, 杨惠珍. 不同品系小鼠对弓形虫速殖子繁殖率影响的比较[J]. 上海实验动物科学, 1989, 9 (2): 110.
	WAN M S , XU K J , YANG H Z . Comparison of the effects of different strains of mice on the reproduction rate of Toxoplasma gondii tachyzoites[J]. Laboratory Animal and Comparative Medicine, 1989, 9 (2): 110.
26	JOHNSON A M . Strain-dependent, route of challenge-dependent, murine susceptibility to toxoplasmosis[J]. Z Parasitenkd, 1984, 70 (3): 303- 309. doi: 10.1007/BF00927816
27	LIESENFELD O . Oral infection of C57BL/6 mice with Toxoplasma gondii: a new model of inflammatory bowel disease?[J]. J Infect Dis, 2002, 185 (Suppl 1): S96- S101.
28	JOHNSON J , SUZUKI Y , MACK D , et al. Genetic analysis of influences on survival following Toxoplasma gondii infection[J]. Int J Parasitol, 2002, 32 (2): 179- 185. doi: 10.1016/S0020-7519(01)00321-6
29	WATSON G F , DAVIS P H . Systematic review and meta-analysis of variation in Toxoplasma gondii cyst burden in the murine model[J]. Exp Parasitol, 2019, 196, 55- 62. doi: 10.1016/j.exppara.2018.12.003
30	吴升伟, 包怀恩, 李小燕, 等. 小鼠感染弓形虫Prugniaud株后的组织病理学变化[J]. 中国寄生虫学与寄生虫病杂志, 2011, 29 (5): 327- 332.
	WU S W , BAO H E , LI X Y , et al. Histopathology changes in mice infected with Toxoplasma gondii prugniaud strain[J]. Chinese Journal of Parasitology and Parasitic Diseases, 2011, 29 (5): 327- 332.
31	赵俊桃. 弓形虫Prugniaud株慢性感染小鼠保护性免疫机制的研究[D]. 南京: 南京医科大学2009.
	ZHAO J T. Study on the mechanism of protective immunity in mice infected with toxoplasma gondii of Prugniaud strain[J]. Nanjing: Nanjing Medical University, 2009. (in Chinese)

目镜视场(FN) field of view	18	20	22	25	26.5
40×物镜下试剂视场面积/mm²	0.16	0.20	0.24	0.31	0.34
Reagent field area under 40×objective lens

分组 Group	小鼠品系 Mouse strain	接种速殖子数量/个 Number of tachyzoites	重复数/只 Number of replicates
K1	KM小鼠	500	6
K2	KM mice	200	6
K3		50	6
K4		10	6
I1	ICR小鼠	500	6
I2	ICR mice	200	6
I3		50	6
I4		10	6
B1	BALB/c小鼠	500	6
B2	BALB/c mice	200	6
B3		50	6
B4		10	6
C1	C57BL/6小鼠	500	6
C2	C57BL/6 mice	200	6
C3		50	6
C4		10	6

引物名称 Primer name	引物序列(5′→3′) Sequence(5′→3′)
外引物前	ACCTTTGAATCCCAAGCA
外引物后	AAGGTGCCATTTGCGTTC
内引物前	TTTGCATTCAAGAAGCGTG
内引物后	AAGGTGCCATTTGCGTTC

程序 Procedure	温度 Temperature	反应时间 Time	循环数 Cycle number
预变性	95℃	5 min	-
变性	95 ℃	50 s	$ \left. \begin{array}{l}\\\\\end{array} \right\}30 $
退火	56 ℃	40 s
延伸	72 ℃	45 s
最终延伸	72 ℃	10 min	-

小鼠编号 ID	450 nm吸光值 OD_{450 nm}	样本值/阴性值 S/N
1	3.138 0	29.600
2	2.978 0	28.094
3	1.806 0	17.037
4	1.041 0	9.821
5	1.179 8	11.130
6	1.461 2	13.785
7	1.661 7	15.676
8	2.162 9	20.405
9	2.261 9	21.339
10	0.889 4	8.391
11	1.183 7	11.117
12	1.134 7	10.705
阴性对照	0.106 0
