畜牧兽医学报 ›› 2024, Vol. 55 ›› Issue (7): 3155-3162.doi: 10.11843/j.issn.0366-6964.2024.07.033

• 基础兽医 • 上一篇    下一篇

负载七叶苷的水凝胶制备及初步评价

丁泽1,2(), 张耀锋1,2, 马蓓1,2, 刘盼1,2, 董天祯1,2, 王天扬1,2, 刘俊峰1,2,*()

  1. 1. 塔里木大学动物科学与技术学院,阿拉尔 843300
    2. 新疆生产建设兵团塔里木动物疫病诊断与防控工程实验室,阿拉尔 843300
  • 收稿日期:2023-09-21 出版日期:2024-07-23 发布日期:2024-07-24
  • 通讯作者: 刘俊峰 E-mail:1425562092@qq.com;ljfdky@126.com
  • 作者简介:丁泽(1998-),男,山西灵丘人,硕士,主要从事兽医临床药理学研究,E-mail:1425562092@qq.com
  • 基金资助:
    兵团指导性科技计划项目,植物提取物敢于奶牛子宫内膜损伤修复创新研究团队(2022ZD100);新疆生产建设兵团塔里木动物疫病诊断与防控工程实验室开放课题(ELDC202201)

Preparation and Preliminary Evaluation of Hydrogel Loaded with Esculin

Ze DING1,2(), Yaofeng ZHANG1,2, Bei MA1,2, Pan LIU1,2, Tianzhen DONG1,2, Tianyang WANG1,2, Junfeng LIU1,2,*()

  1. 1. School of Animal Science and Technology, Tarim University, Alar 843300, China
    2. Tarim Animal Disease Diagnosis and Prevention and Control Engineering Laboratory of Xinjiang Production and Construction Corps, Alar 843300, China
  • Received:2023-09-21 Online:2024-07-23 Published:2024-07-24
  • Contact: Junfeng LIU E-mail:1425562092@qq.com;ljfdky@126.com

摘要:

本试验旨在制备一种可用于局部递送七叶苷的水凝胶。选择羧甲基纤维素钠(CMC-Na)与羧甲基壳聚糖(CMCS)为原料,向其中添加七叶苷(ESC),制备负载七叶苷的CMC-Na/CMCS水凝胶(CCE),并对其性质和功能进行研究。本试验成功制备了CCE水凝胶,并以不同比例的CMC-Na/CMCS设计正交试验,依据载药量和包封率筛选,最终确定水凝胶的配方为2% CMC-Na、2% CMCS、200 μL京尼平,转速为800 r·min-1,水凝胶外观为蓝色溶液,无析出、无杂质、透明度均匀;扫描电镜可见其具有三维结构和许多光滑小孔;粒径为0.841 5 nm,Zeta电位为-32.1 mV; 傅里叶红外光谱和X射线衍射均表明七叶苷成功载入到CMC-Na/CMCS水凝胶中且未影响其原有的官能团;溶胀率为234%;体外释放时间比原料药明显延长;同浓度载药凝胶比原料药抗菌效果有所延长,效果较好。本试验成功将七叶苷载入到了CMC-Na/CMCS水凝胶中,并通过系列试验证明其相较七叶苷原料药具有一定的缓释作用,可以延长药物作用时间,减少给药次数,为临床使用七叶苷治疗疾病提供了一种新的给药方式。

关键词: 羧甲基纤维素钠, 羧甲基壳聚糖, 七叶苷, 水凝胶, 药物递送

Abstract:

The aim of this experiment was to prepare a hydrogel that can be used for local delivery of esculin. Carboxymethyl cellulose sodium (CMC-Na) and carboxymethyl chitosan (CMCS) were selected as the raw materials, to which esculin (ESC) was added to prepare Esculin-loaded CMC-Na/CMCS hydrogel (CCE) for topical drug delivery, and its properties and functions were investigated. In this experiment, the CCE hydrogel was successfully prepared, and orthogonal tests were designed with different ratios of CMC-Na/CMCS, based on the screening of drug loading and encapsulation rate, and the formulation of the hydrogel was finally determined as 2% CMC-Na, 2% CMCS, 200 μL of Genipin, and the rotational speed was 800 r·min-1, and the appearance of the hydrogel was a blue solution, with no precipitation and impurity-free transparency and uniformity; Scanning electron microscopy showed that it had a three-dimensional structure and many smooth pores; the particle size was 0.841 5 nm, and the zeta potential was -32.1 mV; Fourier infrared spectroscopy and X-ray diffraction showed that esculin was successfully loaded into the CMC-Na/CMCS hydrogel without affecting its original functional groups; the solubilization rate was 234%; the in vitro release time was significantly prolonged compared with that of raw materials; the antibacterial effect was prolonged compared with raw materials at the same concentration of loaded gel. The antimicrobial effect was prolonged and better than that of raw materials. In this experiment, we successfully loaded esculin into CMC-Na/CMCS hydrogel and proved through a series of experiments that esculin has a certain slow-release effect compared with the API, which can prolong the action time of the drug and reduce the number of times of administration, providing a new way of administration for the treatment of diseases with Esculin in clinical practice.

Key words: sodium carboxymethyl cellulose, carboxymethyl chitosan, esculin, hydrogel, drug delivery

中图分类号:
